Get more from your entertainment. With crystal clear images and immersive sound, the V6A makes every moment feel real.
UNPARALLELED SOUND
Dolby Atoms® with Height Virtualizer*
For those without in-ceiling or upward firing speakers in their system, Dolby Atmos with Height Virtualization Technology simulates the Atmos experience with forward facing-drivers. Configure up to five speakers to replicate the effect of two in-ceiling speakers, or utilize all seven channels to simulate the powerful effect of four overhead speakers.
Feel every dimension in Dolby Atmos. Enjoy a 5.1 surround speaker system and two additional overhead speakers or two Dolby Atmos elevation speakers, delivering dramatic overhead effects for truly enveloping audio – including Dolby Surround upmixer for legacy content.
*This function is available via FW update.
DTS:X®
DTS:X immersive audio formatting places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. The included spatial remapping engine of DTS Neural:X™ offers improved immersion and heightened realism in all your favourite movies.
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)
160 W (6 ohms, 10% THD)
145 W (6 ohms, 10% THD)
High Slew Rate Amplifier
Yes
Yes
Surround Sound Processing
Surround:AI
N/A
N/A
CINEMA DSP
Yes
Yes
DSP Programs
17
17
Dialog Level Adjustment
Yes
Yes
Virtual Presence Speaker
Yes
Yes
Virtual Surround Back Speaker
Yes
N/A
Dialogue Lift
Yes
N/A
SILENT CINEMA / Virtual CINEMA DSP
Yes
Yes
Dolby Atmos
Yes
N/A
Dolby Atmos Height Virturalizer
Yes (via firmware update)
N/A
Dolby TrueHD
Yes
Yes
Dolby Digital Plus
Yes
Yes
Dolby Surround
Yes
N/A
DTS:X
Yes
N/A
DTS-HD Master Audio
Yes
Yes
Auro 3D
N/A
N/A
Audio Features
File Format
MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 192 kHz / 24-bit, WAV / AIFF: up to 192 kHz / 32-bit, DSD: up to 11.2 MHz
Pure Direct
Yes
Yes
Compressed Music Enhancer
Yes
Yes
High-resolution Music Enhancer
N/A
N/A
YPAO multi-point measurement
Yes
N/A
YPAO Volume
Yes
N/A
Adaptive DRC (Dynamic Range Control)
Yes
Yes
Initial Volume & Maximum Volume Setting
Yes
Yes
A.R.T. Wedge
N/A
N/A
Bi-amp capability
Yes
Yes
Audio Delay
Yes (0-500 ms)
Yes (0-500 ms)
DA Converter
384 kHz / 32-bit BB PCM5102A
384 kHz / 32-bit BB PCM5101A
Video Features
HDMI eARC
Yes
Yes
HDMI Audio Return Channel
Yes
Yes
HDMI Pass-through
8K / 60 Hz, 4K / 120 Hz (via firmware update)
8K / 60 Hz, 4K / 120 Hz (via firmware update)
HDMI Up-scaling
Yes up to 4K
Yes up to 4K
HDMI Up-conversion
N/A
N/A
HDR 10+
Yes (via firmware update)
Yes (via firmware update)
VRR/ALLM/QMS/QFT
Yes (via firmware update)
Yes (via firmware update)
Video adjustment
N/A
N/A
Connectivity
MusicCast Surround
Yes
Yes
HDMI Input/Output
7 / 1
4 / 1
HDMI CEC
Yes
Yes
USB Input
Yes
Yes
Network Port
Yes
Yes
Wi-Fi
Yes (2.4 / 5 GHz)
Yes (2.4 / 5 GHz)
AirPlay
Yes
Yes
Bluetooth
Yes (SBC / AAC)
Yes (SBC / AAC)
Front AV Input
USB
USB
Digital Audio Input/Output: Optical
1 / 0
1 / 0
Digital Audio Input/Output: Coaxial
1 / 0
1 / 0
Analog Audio Input/Output
4 / 0
3 / 0
Phono Input
Yes
N/A
XLR Terminal
N/A
N/A
Component Video Input/Output
N/A
N/A
Composite Video Input/Output
N/A
N/A
Preout
2.2-ch
0.2-ch
Headphone Output
1
1
Tuner Section
FM/AM Tuner
Yes (Availability varies by region.)
Yes (Availability varies by region.)
DAB Tuner
Yes (Availability varies by region.)
Yes (Availability varies by region.)
User Interface
On-screen display
Graphical User Interface
Graphical User Interface
SCENE
Yes (8 sets)
Yes (4 sets)
App Control
Yes (iPhone / iPad / Android phone / tablet)
Yes (iPhone / iPad / Android phone / tablet)
Web Browser Control
Yes
N/A
Remote Control Unit
Yes
Yes
Zone Control
Zone 2 Audio Output
Preout
N/A
Zone 3 Audio Output
N/A
N/A
Zone 4 Audio Output
N/A
N/A
Powered Zone
Zone 2
N/A
Zone Video Output
N/A
N/A
Zone B Output
N/A
N/A
Zone GUI
N/A
N/A
RS-232C Interface
N/A
N/A
+12V Trigger Output
1
N/A
Remote (IR) Input/Output
N/A
N/A
Party Mode
Yes
N/A
General
Standby Power Consumption (IR only)
0.1 W
0.1 W
Auto Power Standby
Yes
Yes
ECO mode
Yes
Yes
Dimensions (W x H x D)
435 W x 171 H x 377 D mm (with antenna up:435W x 245H x 377D mm);17-1/8"W x 6-3/4"H x 14-7/8"D (with antenna up:17-1/8"W x 9-5/8"H x 14-7/8"D)
435 W x 171H x 377D mm (with antenna up:435 W x 245 H x 377 D mm);17-1/8"W x 6-3/4"H x 14-7/8"D (with antenna up:17-1/8"W x 9-5/8"H x 14-7/8"D)
