NAD C316v2 BEE Integrated Amplifier

Limited stock available.

The C 316BEE promises improved power efficiency, a healthy dose of ‘green’ attributes, and serious musical performance. The C 316BEE also offers entry-level affordability, and for many there will never be a need for another amplifier. With class-leading specifications for noise, distortion, power, stereo separation and volume control tracking, the C 316BEE sets new benchmarks for performance, both measured and audible. The sonic result is a relaxed and inviting sound that digs out the subtle details in your favourite recordings and presents them across a panoramic stereo soundstage.

Features

  • PowerDrive
  • 5 Line Level Inputs
  • MM Phono Input for Vinyl
  • Front Panel Input for Portable Media Players
  • Bass and Treble Controls
  • Tone Defeat (Bypass)
  • Headphone Output
  • IR Remote Control
  • Multi-way Speaker Binding Posts
  • Gold Plated RCA Jacks
  • Toroidal Power Transformer
  • <0.5W Standby consumption
nad c316v2 bee integrated amplifier melbourne hi fi
Specifications

Line In / Headphone Out

  • THD (20 Hz – 20 kHz)
  • <0.03 % in 300 ohms at 2 V out
  • Signal-to-Noise Ratio
  • >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)
  • Frequency response
  • ±0.3 dB (20 Hz – 20 kHz)
  • Output impedance
  • 8 ohms

Line In / Speaker Out

  • Continuous output power into 8 ohms and 4 ohms
    40W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
  • THD (20 Hz – 20 kHz)
  • <0.03 % (250 mW to 40 W, 8 ohms and 4 ohms)
  • Signal-to-Noise Ratio
  • >95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
    >97 dB (A-weighted, 500 mV input, unity gain in 32 ohms)
  • Clipping power (at 1 kHz 0.1 % THD)
  • >45 W in 8 ohms
    >60 W in 4 ohms
  • IHF dynamic power
  • 8 ohms: 90 W
    4 ohms: 120 W
    2 ohms: 170 W
  • Damping factor
  • >200 (ref. 8 ohms, 1 kHz)
  • Frequency response
  • ±0.3 dB (20 Hz – 20 kHz, Tone Defeat ON)
    Treble: ± 5dB at 10 kHz
    Bass: ± 8 dB at 100 Hz
  • Channel separation
  • >70 dB (1 kHz)
  • Maximum input level
  • 4.3V (1 kHz THD 0.1%)
  • Input sensitivity (for 40 W in 8 ohms)
  • 200 mV
  • Standby power
  • <0.5 W

Phono In / Speaker Out

  • THD (20 Hz – 20 kHz)
  • <0.03 % (1 W to 40 W, 8 ohms and 4 ohms)
  • Signal-to-Noise Ratio
  • >75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)
  • Frequency response (RIAA deviation)
  • +0.3 dB (20 Hz – 20 kHz, Tone Defeat ON)
  • Maximum input level
  • 71 mV (1 kHz THD 0.1%)
  • Input sensitivity (for 40 W in 8 ohms
  • 2.95 mV

Dimension and Weight

  • Gross dimensions (W x H x D)
  • 17 1/8 x 3 9/16 x 11 1/4 inches
    435 x 90 x 285 mm
  • Net weight
  • 5.5 kg (12.1 lbs)
  • Shipping weight
  • 6.4 kg (14.1 lbs)
