Bowers & Wilkins CWM7.4 S2 In Wall Speaker

by Bowers & Wilkins
Write a review
$1,499.00 - $1,499.00
$1,499.00
$1,499.00 - $1,499.00
$1,499.00

Bowers & Wilkins CWM7.4 S2 In Wall Speaker

Reference 2.5-way in-wall speaker

The Bowers & Wilkins CWM7.4 S2 represents premium in-wall speaker engineering designed for seamless home theatre integration.

Designed for wall-mounted left, centre and right speaker positions in a discreet home cinema system, CWM7.4 S2 can also be mounted beside, above or below the screen. Its 2.5-way configuration features a single Carbon Dome tweeter, twin 100mm (4in) Continuum cone midrange units and twin 100mm (4in) Aramid Fibre/paper bass cones.

Specifications

GENERAL SPECIFICATIONS
Product Type
  • In-Wall Speaker
System Type
  • 2.5-Way In-Wall System
Frequency Range
  • 43Hz - 33kHz (-6dB)
Frequency Response
  • 45Hz - 28kHz ±3dB
Sensitivity
  • 86dB SPL (2.83Vrms, 1m)
Harmonic Distortion
  • <1% (2nd and 3rd harmonics, 90dB, 1m, 80Hz - 33kHz)
  • <0.5% (2nd and 3rd harmonics, 90dB, 1m, 120Hz - 33kHz)
Impedance
  • 8Ω (Nominal)
  • 4.9Ω (Minimum)
Mounting System
  • QuickDogs™
Finish
  • White Grille
DRIVERS
Tweeter
  • 1 x 25mm Carbon Dome Tweeter
Midrange Drivers
  • 2 x 100mm Continuum™ Cone Mid/Bass Drivers
Bass Drivers
  • 2 x 100mm Aramid Fibre/Paper Profile Bass Drivers
INSTALLATION SPECIFICATIONS
Pre-Mount Kit
  • PMK CWMC7
DIMENSIONS AND WEIGHT
Dimensions
  • 175mm Width
  • 92.5mm Depth (behind surface)
    • 8mm Protrusion (in front of surface)
  • 625mm Height
Cut-Out
  • 149mm Width
  • 599mm Height
Weight
  • 6.2kg
