KEF Ci160TR In-Wall Speaker

Requiring less than 36mm of mounting depth, the Ci160TR fits snugly in very narrow ceiling spaces and is therefore specified for demanding applications such as today’s luxury high-rise apartments and your music system.

Features

  • <36mm mounting depth allows fitment to very restricted cavities
  • Ultra-low profile LF unit with excellent bass extension
  • Vented tweeter with KEF’s unique ‘tangerine’ waveguide for natural HF response and wide, even dispersion
  • Rigid flat diaphragm assures clean upper bass and mid-range response
  • Paintable Ultra-Thin Bezel (UTB) and magnetic grille to blend unobtrusively with décor
  • Fast, versatile installation on virtually any surface via dogleg or direct screw fastening



Model Ci160TR
Series T Series
Nominal impedance
Sensitivity (2.83V/lm) 87dB
Frequency response (±6dB) open-backed 110Hz-24kHz
Crossover frequency 1.7kHz
Drive units LF: 115mm (4.5 in.) dual layer MF
HF: 25mm (1 in.) aluminium HF
Recommended amplifier power 10-100W
Product external dimensions Diameter: Φ234.6mm (Φ9.24 in.)
Depth: 40mm (1.57 in.)
Cut-out dimensions Φ196mm (Φ7.71 in.)
Net Weight 1 kg
Mounting depth from surface 36mm (1.42 in.)
Minimum wall thickness 10mm (0.39 in.)
Maximum wall thickness 25.5mm (1 in.)
Optional rough in frame RIF160R
Optional rear enclosure RNC160R
